Radial Segment Diamond Cut and Grind Blade
Model: DSB-115125-S-T-RS
Product Type: Double-sided hot-pressed diamond cutting and grinding blade with straight radial segment pattern.
Available Sizes: 115 mm and 125 mm.
Bore: 22.23 mm.
Working Layer Thickness: 1.6 mm.
Working Layer Height: 25 mm.
Blade Shape and Function: Long straight radial diamond strips form open evacuation channels across the 25 mm working area. This pattern promotes fast dust and slurry removal, keeps the cutting zone open and gives the blade an aggressive but controllable grinding action.
Applications: Ceramic tile, porcelain, gres, Dekton-type sintered stone, marble, quartz and engineered stone.
Recommended Operations: Straight cutting, 45° mitre cutting, chamfering, edge shaping and light surface grinding with a compatible angle grinder. Suitable for dry or wet work; water improves cooling and dust control.
Advantages:
• Open radial channels for efficient debris removal
• Wide double-sided diamond area for cutting and grinding
• Stable control during 45° bevel work
• 1.6 mm cutting thickness and 25 mm working height
• Available in 115 mm and 125 mm
Confirm maximum RPM and machine compatibility before use.
