ZSCWR003
ZHOUSHI
6804219000
· Classic double-row layout provides broad and stable grinding contact.
· Balanced choice for general concrete and screed applications.
· Suitable for leveling, laitance removal and masonry preparation.
· Open body windows support dust extraction and cooling airflow.
· Multiple bond, grit, segment height, color and packaging options are available.
Item | Specification / Recommendation |
Outer Diameter | 125mm / 5 inch |
Bore | 22.23mm |
Segment Design | Double row; approximately 18 segments (confirm production count) |
Recommended Machine | Compatible angle grinder or concrete hand grinder with correct flange, guard and dust shroud |
Working Method | Dry grinding with dust extraction; wet use only after the exact production version is confirmed suitable |
Target Finish | Medium / general-purpose grinding |
OEM Options | Bond, grit, segment height, body color, laser marking and packaging—subject to confirmation |
Maximum Speed | Follow the permanent marking on the delivered wheel; never exceed the wheel-rated speed |
Item | Specification / Recommendation |
Recommended | Concrete, screed and masonry; leveling and routine surface preparation |
Not Recommended / Select Another Tool | Use an arrow or PCD wheel when the main task is thick coating or adhesive removal. |
The 125mm double-row diamond cup wheel is a widely used general-purpose tool for grinding concrete, screed and masonry. Its two rows of diamond segments create broad, stable contact and provide a useful balance between removal speed, surface finish and working life.
It can be used to level uneven areas, remove laitance and prepare a substrate before repair or coating. Operate it with a compatible angle grinder, guard and dust shroud. Keep the wheel moving and use overlapping passes to avoid local gouging.
· Confirm the wheel bore, grinder flange, maximum speed and rotation direction before mounting.
· Use the correct guard, safety glasses, hearing protection and a dust-extraction shroud connected to a suitable vacuum.
· Start with light to moderate pressure. Keep the wheel flat and move it continuously in overlapping passes.
· Do not force the wheel, grind with a damaged wheel or exceed the speed marked on the product.
· Inspect the wheel and mounting system before each use. Follow the grinder manufacturer’s instructions and local safety requirements.
Please send us your grinding material, machine model, required bore, target finish and expected order quantity. We will recommend the suitable bond and diamond grit for the 125mm double row cup wheel and provide OEM marking, color and packaging options.
