| Quantity: | |
|---|---|
ZSDBX125
ZHOUSHI
8202391000
Model: | ZSDBX125 |
Application: | For cutting Porcelain, Granite, Marble, Brick, Dekton, Quartz etc. |
Feature: | Fast cutting, no chipping |
Working condition: | Both dry and wet |
Segment type | X turbo |
Diameter: | 75-350mm |
Machinery: | Angle grinder, Pneumatic grinder, marble cutter, portable tile cutter, table saw |
Color: | Can be customized with a Pantone code or RAL code |
Package: | Carton box, Blister, and customized package is available with a MOQ request. |
Sizes available:
Diameter | Segment Thickness | Segment Height | Hole Size | RPM |
75mm(3”) | 1.2mm | 10mm | 10/16/20/22.23/25.4/30/50/60mm | |
100mm(4”) | 1.2mm | |||
115mm(4.5”) | 1.2/1.4mm | 13,300 | ||
125mm(5”) | 1.2/1.4mm | 12,200 | ||
150mm(6”) | 1.4mm | |||
180mm(7”) | 1.4mm | 8,500 | ||
200mm(8”) | 1.6mm | |||
230mm(9”) | 1.8mm | 6,640 | ||
250mm(10”) | 1.8mm | |||
300mm(12”) | 2.0mm | 6,200 | ||
350mm(14”) | 2.2mm | 4,300 |
