ZSCDB0G68
ZHOUSHI
8207501000
This page features model ZSCDB0G68 with a 68 mm diameter and 1/2 GAS connection for wet drilling porcelain, ceramic tile and sintered stone. The tables below include options across the wider crown-segment range. Confirm the exact connection, segment dimensions and working length for your machine before ordering.
Model: | ZSCDB0G68 |
Application: | Drilling ceramic, porcelain, white dekton, sintered stone etc. |
Feature: | Fast drilling, no chipping, long life |
Working condition: | With water |
Segment type: | Crown segments |
Segment thickness | 1.2mm, 1.5mm, 2.0mm |
Thread type: | M14&1/2GAS |
Size: | 6-150mm |
Segment height: | 10mm |
Total length: | 65mm, 90mm, can be customized |
Machinery: | Angle grinder, CNC machine |
Package: | PVC Plastic Tube, Paper Box, Blister, can be customized |
Available sizes:
Diameter(mm) | Segment Size | Thread available |
Φ6 | Crown Segment 1.2*10mm 1.5*10mm | M14, 5/8’’-11, M10, M14&1/2GAS |
Φ8 | ||
Φ10 | ||
Φ12 | ||
Φ14 | ||
Φ16 | ||
Φ18 | ||
Φ20 | ||
Φ25 | ||
Φ30 | ||
Φ32 | ||
Φ35 | ||
Φ38 | ||
Φ40 | ||
Φ45 | ||
Φ50 | ||
Φ60 | ||
Φ68 | ||
Φ70 | ||
Φ80 | 20*2.5*10mm | |
Φ90 | 20*2.5*10mm | |
Φ100 | 24*2.5*10mm |
Required diameter and connection, including confirmation of 68 mm and 1/2 GAS for this model.
Material or slab brand, thickness and hole depth.
Machine model, spindle or tool-holder details, and water-cooling setup.
Sample quantity and planned order quantity.
Destination country and packaging requirements.
Include a photo or drawing of the machine connection when checking a replacement tool. This product requires wet drilling with a suitable water supply. For custom lengths, logo or packaging enquiries, send the requirements with your quantity.
