M14&1/2GAS Diamond Drill Bit Ceramic Drill Bit Porcelain tile Hole Saw

Application: For drilling all kinds of porcelain, white dekton, etc.
Type: Sintered crown segment, silver brazed
Segment thickness: 1.2mm, 1.5mm(6-50mm)
Thread: M14&1/2GAS
Working condition: Wet
Machinery: Angle grinder, CNC machine

Availability:
Quantity:
  • ZSCDB008

  • ZHOUSHI

  • 8207501000

Model:

ZSCDB008

Application:

Drilling ceramic, porcelain, white dekton, sintered stone etc.

Feature:

Fast drilling, no chipping, long life

Working condition:

With water

Segment type:

Crown segments

Segment thickness

1.2mm, 1.5mm, 2.0mm

Thread type:

M14, 5/8’’-11, M10, 1/2GAS

Size:

6-50mm

Segment height:

10mm

Total length:

65mm, 90mm

Machinery:

Angle grinder, CNC machine

Package:

PVC Plastic Tube, Paper Box, Blister, can be customized


Sizes available

Diameter(mm)

Segment Size

Thread available

Φ6








Crown Segment

1.2*10mm

1.5*10mm











M14, 5/8’’-11, M10, M14&1/2GAS

Φ8

Φ10

Φ12

Φ14

Φ16

Φ18

Φ20

Φ25

Φ30

Φ32

Φ35

Φ38

Φ40

Φ45

Φ50

Φ60

Φ68

Φ70

Φ80

20*2.5*10mm

Φ90

20*2.5*10mm

Φ100

24*2.5*10mm
